Description
Weiss PSU102
CLEAN POWER FOR YOUR SYSTEM
universal power supply unit
Your high-end devices deserve to be supplied with the cleanest, quietest, and most stable power possible. Built to the standard of all other Weiss devices, the PSU102 includes a discrete voltage regulator and an extremely low noise floor capable of driving heavy loads.
Users highlight the advantages of pairing the DAC204 with the PSU102 for enhanced performance.
“Yesterday, I installed my new PSU102 to go with the DAC204, which I bought earlier this summer. Every music lover should have one. I didn´t believe that the 204 could be improved, but out of curiosity, I just had to give the 102 a try. The combination of these two products is absolutely marvelous.” C. Hedin
Specifications
Outputs:
Two Fischer brand two-pin sockets, wired in parallel. The corresponding Fischer plugs are S 102 A051-130+ with the E3 102.5/3.5 cable clamp.
- Output voltages selectable: 5V, 6V, 9V, 12V.
- Output current: Up to 1.5A with the two sockets combined.
Mains Power:
- Mains Voltage: 100-120 / 200-240 Volt.
- Fuse rating: 500 mA slow blow at the 115V setting and 250 mA slow blow at the 230V setting.
- Power consumption: 30VA max.
