Description
Denon PMA-A110 : Integrated Amplifier
The Denon limited series Anniversary Edition silver graphite PMA-A110 integrated amplifier delivers best in class audio performance for a best in class audio experience.
Specifications : Â Denon PMA-A110
| Channels |
2 |
| 110th Anniversary Audio Tuning |
Yes |
| All black interior |
Yes |
| Exclusive A110 speaker terminals |
Yes |
| Aluminium Top Cover |
Yes |
| Aluminium Feet |
Yes |
| Digital in: USB-B / optical / coaxial / USB-A |
1 / 3 / 1 / No |
| Sample Rate digital In |
192 kHz / 24-bit |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 |
<=DSD11.2 |
| USB-B PCM sample rate |
384 kHz / 32-bit |
| Quad DAC Configuration |
Yes |
| DAC chip |
4x PCM1795, Burr Brown
Mono-Mode |
| Asynchronous mode rear USB |
Yes |
| Bit-perfect transmission |
Yes |
| Ground isolator for DAC Mode operation |
Yes |
| AL 32 Processing |
ULTRA AL32 |
| DAC Master Clock Design |
Yes |
| Streaming audio from PC |
Yes |
| Analogue Mode |
Yes |
| UHC-MOS single push pull circuit |
7th Generation |
| LC mounted twin transformer |
Yes |
| Wide range amplifier |
Yes |
| High current dynamic power supply |
Yes |
| Power amp discrete construction |
Yes |
| Balance / Bass / Treble / Loudness |
Yes / Yes / Yes / No |
Others
| Shottky diodes |
Yes |
| Solid Heat Sinks |
Yes (BLACK) |
| Source Direct |
Yes |
| Power Amp direct |
Yes |
Inputs Outputs
| Audio Inputs |
5 |
| Digital in: USB-B / optical / coaxial / USB-A |
1 / 3 / 1 / No |
| Phono Input: MM / MC |
Yes / Yes |
| Audio Outputs |
1 |
| Power Amp Direct IN |
Yes |
| Gold plated Cinch |
Yes |
| Number of terminals |
4 |
| Remote Control Bus in / out |
Yes |
| Headphone Out |
Yes |
Specifications
| Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%) |
80 W |
| Output power 4 Ohm (1 kHz, T.H.D. 0.7%) |
160 W |
| Total Harmonic Distortion |
0.01% |
| Input Sensitivity: MM |
2.5 mV / 47 kohm |
| Input Sensitivity: MC |
200 uV-100 ohm |
| Signal to Noise Ratio: MM/MC |
89 dB / 74 dB |
| Input Sensitivity: High level |
135 mV / 47 kohms |
| Signal to Noise Ratio: High level |
110dB |
| Treble Control |
± 8 dB at 10 kHz |
| Bass Control |
± 8 dB at 100 Hz |
General
| Available colors: Premium Silver / Black |
Silver Graphite |
| Metal Front Panel |
Yes |
| Power Consumption in W |
400 |
| Standby Consumption in W |
0.2 |
| Auto Power Off |
Yes |
| Detachable Power Cable |
Yes |
| Remote Control |
RC-1237 |
| System Remote Function |
Yes |
| Maximum Dimensions (W x D x H) in mm |
434ｘ450ｘ182 |
| Weight in kg |
25 |
| Carton Maximum Dimensions (W x D x H) in Inches |
573 x 533 x 317 |
| Carton Weight (inc. product) in LBS |
29.8 |
